Bevelling tool for metal
KFMVP 17-15 F (601771620) Bevelling tool for metal
Article number: 601771620
Your Delivery Scope
(120 V / 50 - 60 Hz)
metaBOX 185 XL
- 1700 WRated input power
- 15 mm / 19/32 "Max. chamfer height at 45°
| No-load speed | 6200 - 12000 rpm |
| Rated input power | 1700 W |
| Output power | 880 W |
| Type of edges | Chamfer |
| Chamfer angles | 0 - 90 ° |
| Max. chamfer width 45° | 21 mm / 13/16 " |
| Max. chamfer height at 45° | 15 mm / 19/32 " |
| Grading of cutting depth setting | 0.1 mm / 0.00394 " |
| Curves smallest outer Ø | 100 mm / 3 15/16 " |
| Weight (without power cable) | 6.3 kg / 13.8 lbs |
| Cable length | 3.9 m / 13 " |
| Vibration | 5 m/s² |
| Uncertainty of measurement K | 1.5 m/s² |
| Sound pressure level | 99 dB(A) |
| Sound power level (LwA) | 107 dB(A) |
| Uncertainty of measurement K | 3 dB(A) |
| 3 Carbide indexable inserts Universal |
| Stop roller |
| Screwdriver for Torx screws 15 |
| Screwdriver SW 4 with T-handle |
| Open-jawed spanner SW 10 |
| Bow-type handle |
| metaBOX 185 XL |
